Place of Origin: Hebei, China (Mainland)
Brand Name: QIANWEI
Model Number: ADSS
Type: Cat 7
Number of Conductors: ≥ 10
Fiber Count: 4-144 cores
Jacket: PE or AT
Strength Member: Non-metal member
Temperature range: -40°~60°C
Application: Aerial or duct
Loose: PBT
Color: Black
| Packaging Details: | Wooden reel with test report or according to your requirements |
|---|---|
| Delivery Detail: | 10-30 days after payment |
ADSS cable is made of non-metallic material and self-supporting with the aerial power transmission line. The tension resistance material is aramid yarn with high elasticity modules. And optimizing structure can deploy the weight of the cable and its mechanical and physical properties appropriately and minimize the load on the tower.
1.Lightness, small outer diameter, no torsion, high tensile resistance
2.High modular of elasticity, suitable for large stress-strain
3.Small thermal expansion coefficient
4.Good vibration resistance
5.Excellent flexibility capability
6.Free from lighting, and electric-magnetic interrupt
7.Adapt different span and sag installation requirements through changing sectional area of aramid fibers in the cable
Application
1.Install on the same pole or tower with high voltage power transmission line within 220KV.
2.Not rely on eclectic phase wire or ground wire, can be executed on an electric circuit.
3.Communication and electrical power transmission are different system; and the installation, maintenance and repair can be operated with no influence on each other.
4.Calculate out the electric field and sag accurately by computer to ascertain the best installation place.
